Prime Property in the Right Location
Situated east of Red Lake in Northwestern Ontario, this property boasts excellent access through well-maintained forest roads and is close to key infrastructure, including a nearby transmission line. With plenty of space for development, it’s ideally located for future mining projects.
Prime Location
Positioned 64 km east of Red Lake in Northwestern Ontario, Canada, a prime mining region, with coordinates 92° 15' 16" W, 50° 59' 00" N
Efficient Access
The property is accessible via a network of primary, all-weather forest roads, which are regularly maintained by the forest license holder for year-round access
Local Resources
A 115 kV transmission line located within 5 km of the property, with ample land available for surface plant and tailings pond development
Property Geology And Geophysics With New Targets Areas
Several new targets have been identified, including strong VTEM conductors near the D Zone and South Contact Zone, as well as areas linked to the Upper Alteration Cell. A complex structure area also shows potential, where historic drilling missed some mineralization. These targets will be ground-truthed and prioritized for drilling in 2025.
D Ext
A strong VTEM Conductor on-strike towards the D Zone.
Upper New1
A strong VTEM Conductor associated with Upper Alteration Cell.
Upper New2
A moderate VTEM Conductor associated with Upper Alteration Cell
Upper New3
A moderate VTEM Conductor associated with Upper Alteration Cell.
South Ext
A moderate VTEM Conductor on-strike towards the South Contact Zone.
Structure Complex
A area of intense structural complexity where some mineralized zones were unsampled in historic drill-holes.
Exploration Models
The property offers several exploration models with strong potential, including VMS deposits rich in copper and zinc, as well as hydrothermal vents and copper-gold mineralization. Areas of structural complexity also suggest the presence of silver-gold veins, highlighting exciting opportunities for further exploration.
1. Volcanic Hosted Massive Sulphides
VMS deposits are key sources of copper and zinc, and their high density and EM properties enhance exploration through geophysical techniques. An example at this project is the Arrow Deposit
2. Hydrothermal Vent in VMS System
The D-Zone is a possible example of a hydrothermal vent within the VMS system.
3. Copper-Gold Rich Pipes in VMS System
The Upper Alteration Cell contains examples of copper-gold rich pipes within the VMS system
4. Ag-Au Veins Overprinting VMS System
There is potential for silver-gold veins overprinting the VMS system, with unsampled mineralization found in historic drill holes within areas of intense structural complexity
Property Geology
The property in Red Lake features several promising mineralized zones, including the D-Zone, E-Zone, Hornet Zone, and Arrow Zone. These zones show high-grade copper, zinc, gold, and silver mineralization, with a strong potential for further exploration and development.
D-Zone (DDH #29 Hole)
0.32oz/t Au, 1.75% Cu, 0.86% Zn, and 7.7oz/ton Ag over 3.4 meters
Arrow Zone
High-grade core of 490,000 tonnes @ 1.35% copper, 17.87% zinc, 0.86 g/t Au and 36.1 g/t Ag
E-Zone
1.08% Cu, 8.28% Zn, 0.39oz/t Ag
Hornet Zone
1.13% Cu, 4.07% Zn, 61.1 ppm Ag
Drill Hole Map
The drill hole map outlines the locations of key exploration holes across the property. A corresponding list of drilled holes offers an overview of the areas targeted during the exploration process.
Property Status
The property covers over 3,000 hectares and includes 143 mining claims. Exploration activities are permitted under recently issued exploration permits, allowing for drilling, line cutting, and surveys over the next three years.
Mining Claims
The property consists of 143 mining claims, including 119 single-cell claims, 3 multiple-cell claims, and 21 boundary claims, covering an area of 3,000.4 hectares (approximately 7,414 acres).
Exploration Permits
Permits PR-24-000054, 000055, 000056, and 000057 allow diamond drilling, stripping, line cutting, and electro-magnetic surveys using a generator. These permits were issued on May 23rd, 2024, and are valid for a period of three years.
Topography and Access Roads
The 2021-2030 Forest Management Plan includes the development of a new access road, Slash Road, which will enhance road access to all areas of the property, improving accessibility for exploration and future development.
